AXLE ASSY 15" MAXUS 3-SPOKE 77" TRACK

Product Code: AP0252MG770

$4,476.15
Afterpay Logo
Unavailable for this order
My Store:
Change Store
Select your store to check the availibility
Increase value Decrease value
Description
MAXUS Axle Assemly. 3 spoke axle, nil ABS, 77 inch track and 6 inch tube.

MAXUS Axles are manufactured to strict quaility standards.
  • Key Features
  • Specifications
  • Documents
  • Warranty
Technical Specifications
Axle Diameter (mm) 127
Bearing Type HM212049/011 - HM218248/210
Brake Size (Inches) 12.2" x7.5"
Colour Black
Height (mm) 365
Hub Type (Spoke/Stud/PCD) 6-3/4" -10UNC/317.5
Length (mm) 2252
Track (mm) 1957
Wall Thickness (mm) 16
Width (mm) 365
Available in Pack Quantity of
1
